VLT® HVAC Drive FC 100 Danfoss VLT® HVAC Drive is dedicated to ventilation, heating, and refrigeration applications. With a wide range of powerful standard and optional features, the VLT® HVAC Drive... Range 200-240 V.....1.1 kW - 45 kW 380-480 V.....1.1 kW-1000kW 525-600 V.....1.1 kW - 90 kW 525-690 V.....45 kW - 1,4 MW Enclosures IP20/chassis, IP21/NEMA 1,IP55/NEMA 12 and IP66/NEMA 4X Serial Communication Options Profibus Option Card (MCA-101) DeviceNet Option Card (MCA-104) BACnet (MCA-109) Lonworks (MCA-108) I/O options General Purpose I/O (MCB 101) Relay Option (MCB 105). External 24VDC supply option (MCB-107). Analogue I/O w. real time clock backup (MCB-109). Filters Harmonic Filter (AHF 005/010 MCE) Sine-Wave Filters (MCC 101) dU/dt filter (MCC 102)	VLT® AQUA Drive FC 200 Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful standard and optional features, the VLT® AQUA Drive provides the lowest ... Power and Voltage Range 200-240 V.....0.25 kW - 45 kW 380-480 V.....0.37 kW - 1000kW 525-600 V.....0.75 kW - 90 kW 525-690 V.....45 kW - 1.4 MW Three Phase 3200-240V… 0.25-45kW 3380-480V… 0.37-1000kW 3525-600V… 0.75-90kW 3525-690V… 11-1200kW Single Phase 1200-240V 1.1-22kW 1380-480V 7.5-37kW Enclosures IP20/chassis, IP21/NEMA 1, IP55/NEMA 12 and IP66/NEMA 4X Serial Communication Options Profibus Option Card (MCA-101) DeviceNet Option Card (MCA-104) Ethernet IP (MCA-121) I/O Options General Purpose I/O (MCB 101), Relay Option (MCB 105), Extended cascade option (MCO-101), Advanced cascade option (MCO-102), Analogue input option (MCB109), External 24VDC supply option (MCB-107) Sensor input option (MCB114) Filters Harmonic Filter (AHF 005/010 MCE) Sine-Wave Filters (MCC 101) dU/dt filter (MCC 102)	VLT® AutomationDrive FC 300 The VLT® AutomationDrive is a single drive concept that covers the entire range of application, which is a major benefit in commissioning, operating and maintaining the equipment... Range 0.25 - 37 kW (200 - 240 V) 0.37 - 800 kW (380 - 500 V) 0.75 - 75 KW (525 - 600V) 11 kW – 1.4 MW (525 - 690V) Enclosures The drive meets requirements for enclosure class IP 20/Chassis. Optional IP21/NEMA 1, IP55/NEMA 12, IP 54/NEMA12 or IP66 NEMA 4X. Fieldbus Options PROFIBUS DP V1 (MCA 101) DeviceNet (MCA 104) CAN Open (MCA 105) PROFINET (MCA 120) EtherNet IP (MCA 121) Modbus TCP (MCA 122) I/O Options General Purpose I/O (MCB 101) Encoder Input (MCB 102) Resolver Input (MCB 103) Relay Option (MCB 105) Safe PLC I/O (MCB 108) PTC Thermistor Card (MCB 112) Ext. Relay Card (MCB 113) VLT Sensor Input (MCB 114) Power Options Advanced Harmonic Filter (AHF 005/010 MCE) Sine-Wave Filters (MCC 101) dU/dt filter (MCC 102)


VLT® High Power Drives Danfoss VLT® HVAC Drive is dedicated to ventilation, heating, and refrigeration applications. With a wide range of powerful standard and optional features, the VLT® HVAC Drive... Small is not only beautiful, but also very practical. The new Danfoss High Power Drives offer a number of important advantages: • Dimensions and weights are reduced by an average of 35 percent, making the High Power Drives easy to fit into very small installation spaces • Available in IP00, IP21 (NEMA 1) and IP54 (NEMA 12) enclosures • Built-in DC coils for harmonic suppression, RFI filters, mains switch and fuses • The smallest complete drives in their power range available today • IP00 enclosures suitable for building in a standard Rittal 1800 or 2200 mm cabinet • Easy maintenance because all parts are accessible through the front meaning drives can also be installed side-by-side, saving even more space • High efficiency (>98%), less cooling energy • Innovative Back Channel Cooling concept, keeping 85% of the excess heat out of the drive and the panel or cabinet • Pedestal making it possible to place the drive on the floor • Offers all the features and benefits of the new generation Danfoss VLT® AutomationDrive, VLT® HVAC Drive and VLT® AQUA Drive	VLT® Low Harmonic Drives Danfoss VLT® AQUA Drive is dedicated to water and wastewater applications. With a wide range of powerful standard and optional features, the VLT® AQUA Drive provides the lowest ... Power Range 132-630 kW (High Overload) 160-710 kW (Normal Overload) Voltage Range 380-480 Vac 50-60 Hz Enclosure IP21 / NEMA1, IP54 hybrid Harmonic Mitigation Performance <5% THD - Meets individual harm. levels of IEEE 519 for ISC/IL>20	VLT® 2800 Series The VLT® AutomationDrive is a single drive concept that covers the entire range of application, which is a major benefit in commissioning, operating and maintaining the equipment... Product Range 0.55 - 18.5 kW (3 phase 380 - 480 V ± 10 %; 50/60 Hz) 0.37 - 1.5 kW (Combined 1 and 3 phase 200 - 240 V ± 10 %; 50/60 Hz) 2.2 - 3.7 kW (3 phase 200 - 240 V ± 10 %; 50/60 Hz) Variable output frequency between 0 and 1000 Hz Communication DeviceNet ModBus RTU Metasys N2 Profibus DP, optional EMC Filter and DC Coils Compliance with EMC Standards. Built-in EN 55011 1A filter, 25 m screened cable. No EMC disturbance. EN 55011 1B filter available as module. IT mains compatible version with RFI filter (up to 4 kW). VLT 2880-2882 with RFI-switch.


VLT® Micro Drive The VLT® Micro Drive is a general purpose drive that can control AC motors up to 22.0 kW. It is a small drive with maximum strength and reliability. RoHS compliant The VLT® Micro... VLT® Micro Drive is a genuine VLT® frequency converter with unsurpassed reliability, user-friendliness, condensed functionality, and extremely easy to commission. Terminal numbers are named in the same manner as in the rest of the VLT® family. Despite the compact size and the easy commissioning, VLT® Micro Drive can be set up to perform perfectly even in complex application set-ups. Approximately 100 parameters can be set to optimize energy efficiency and operation. Coated PCB Standard For harsh environments. Real Space Saving Side-By-Side A compact book style design allows real side by side mounting without derating. Minimum Penetration of Dust VLT® Micro Drive is designed to keep the forced ventilation away from the electronics. Printed circuit boards are well protected inside the drive. Built-in RFIM Radio disturbance from motor cables is limited with the built-in RFI filter allowing for 15 m motor cables (screened). Meets EU norms. Built-in Brake Functions With built in DC and AC brake functions, VLT® Micro Drive can transform kinetic energy in the application into braking power to slow down the motor. A brake chopper is built-in the drives from 1.5 kW upwards. Product Range 1 x 200–240 V AC 0.18–2.2 kW 3 x 200–240 V AC 0.25–3.7 kW 3 x 380–480 V AC 0.37–22.0 kW Fieldbus Communication FC Protocol Modbus RTU
